4
ASSEMBLY INSTRUCTIONS
1
2
P
J
K
N
O
N
Front view
#3 ø7 Lock Washer(X6)
#1 1/4"-20UNCx13 Screw(X6)
#2 ø7 Flat Washer(X6)
Separate the 2 different types of wheels, 2 locking wheels
(O) and 2 regular wheels (P).
Attach the locking wheels (O) to the back of the bottom
shelf (N) and the regular wheels (P) to the front of the
bottom shelf (N).
To secure the 4 wheels, hand tighten first. Then, tighten
further using the wrench provided in the hardware pack.
Ensure that the wheels are firmly locked in the “ON” position
before continuing.
Assemble the left side panel (J) and the right side panel (K)
to the bottom shelf (N).
