Replacing the Display Hinges
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before Working Inside Your Computer . After working inside your
computer, follow the instructions in After Working Inside Your
Computer . For more safety best practices, see the Regulatory
Compliance home page at dell.com/regulatory_compliance.
Procedure
NOTE: These instructions are only applicable for laptop with non-
touchscreen display.
1 Align the screw holes on the display hinges with the screw holes on the
display back-cover.
2 Replace the screws that secure the display hinges to the display back-
cover.
Post-requisites
1 Replace the display bezel .
2 Replace the display assembly .
3 Replace the power-adapter port .
4 Follow the procedure from step 3 to step 9 in “Replacing the Palm Rest ”.
5 Replace the keyboard .
6 Follow the procedure from step 4 to step 5 in “Replacing the Optical
Drive ”.
7 Follow the procedure from step 4 to step 6 in “Replacing the Hard Drive ”.
8 Replace the base cover .
9 Replace the battery .
91
