Replacing the Hard Drive
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before Working Inside Your Computer . After working inside your
computer, follow the instructions in After Working Inside Your
Computer . For more safety best practices, see the Regulatory
Compliance home page at dell.com/regulatory_compliance.
CAUTION: Hard drives are fragile. Exercise care when handling the
hard drive.
Procedure
1 Adhere the Mylar sheet to the hard drive.
2 Align the screw holes on the hard-drive bracket with the screw holes on
the hard drive.
3 Replace the screws that secure the hard-drive bracket to the hard drive.
4 Place the hard-drive assembly on the computer base.
5 Slide the hard-drive assembly to secure the hard-drive connector with
the system-board connector.
6 Replace the screw that secures the hard-drive assembly to the computer
base.
Post-requisites
1 Replace the base cover .
2 Replace the battery .
