Dell Precision M6800 (Late 2013) - Manual (Page 21)

Removing the Secondary Hard Drive
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the:
a) battery
b) base cover
3. Remove the screw that secure that secondary hard drive in place.
4. Pull the tab upward and remove the secondary hard drive from the computer.
5. Remove the screw that secure secondary hard drive to the bracket.
6. Remove the secondary hard drive from the bracket.
Installing the Secondary Hard Drive
1. Engage the secondary hard drive bracket to the secondary hard drive.
2. Tighten the screw that secure the secondary hard drive bracket.
3. Install the secondary hard drive into the computer.
4. Tighten the screw that secure the secondary hard drive in the computer.
21
