60 | Replacing the Display Hinges
Replacing the Display Hinges
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 7. After working inside your computer, follow the instructions in "After
Working Inside Your Computer" on page 9. For additional safety best
practices information, see the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Procedure
1 Align the screw holes on the display hinges with the screw holes on
the display back-cover.
2 Replace the screws that secure the display hinges to the display back-cover.
Postrequisites
1 Replace the display bezel. See "Replacing the Display Bezel" on page 57.
2 Replace the display assembly. See "Replacing the Display Assembly" on page 54.
3 Replace the palm-rest. See "Replacing the Palm-Rest" on page 27.
4 Replace the keyboard. See "Replacing the Keyboard" on page 23.
5 Replace the optical-drive assembly. See "Replacing the Optical-Drive Assembly" on
page 17.
6 Replace the hard-drive assembly. See "Replacing the Hard-Drive Assembly" on
page 20.
7 Follow the instructions from step 3 and step 4 in "Replacing the Memory Module(s)"
on page 14.
8 Replace the battery. See "Replacing the Battery" on page 11.
