About Your Computer
19
Bottom View
BATTERY — When a battery is installed, you can use the computer without
connecting the computer to an electrical outlet.
BATTERY RELEASE LATCH — Releases the battery.
BATTERY CHARGE / HEALTH GAUGE BUTTON — Press this button to get information
on the battery charge and battery health.
1 battery 2 battery release latch
3 battery charge/health gauge 4 battery charge/health gauge button
5 base cover
