10
About Your Computer
CAMERA INDICATOR ( OPTIONAL ) — Indicates that the camera is turned on. Based on
configuration selections you made while ordering, your computer may not include a
camera.
CAMERA ( OPTIONAL ) — Built-in camera for video capture, conferencing, and chat.
Based on configuration selections you made while ordering, your computer may not
include a camera.
DISPLAY — For more information about your display, see Dell Technology Guide.
MEDIA CONTROL BUTTONS — Control CD, DVD, and Media Player playback.
1 camera indicator (optional) 2 camera (optional)
3 display 4 media control buttons
5 num lock light 6 device status lights
7 power button 8 battery status light
9 AC adapter connector 10 USB connectors (2)
11 optical drive 12 microphone connector
13 headphone connectors (2) 14 fingerprint reader (optional)
15 consumer IR 16 integrated single analog microphone
17 touch pad buttons 18 touch pad
19 keyboard 20 caps lock light
21 dual digital array microphones
(optional)
Launch Dell MediaDirect Mute the sound
Play the previous track Turn the volume down
Stop Turn the volume up
Play or pause Eject the disc
Play the next track
