Electrical Specifications
Model AW2210
Video input signals Digital DVI-D TMDS, 600 mV for each differential line, positive polarity at
50 ohm input impedance
HDMI TMDS, 600 mV for each differential line, positive polarity at 50 ohm
input impedance or 100 Ohm per differential pair
Audio Input and Output signals : Input signal
level: 1 Vrms without clipping
Synchronization input signals Separate horizontal and vertical synchronizations, polarity-free TTL level,
SOG (Composite SYNC on green)
AC input voltage/frequency/current 100 to 240 VAC/50 or 60 Hz + 3 Hz/1.5 A (Max.)
Inrush current 120V:40A (Max.)
240V:80A (Max.)
Physical Characteristics
Model AW2210
Connector type DVI-D, white connector; HDMI, black connector
Signal cable type Digital: Detachable, DVI-D, Solid pins, shipped detached from the monitor
High Deinition Multimedia Interface: Detachable, HDMI, 19 pins
Dimensions (with stand)
Height 18.14 inches (460.82 mm)
Width 20.33 inches (516.27 mm)
Depth 7.64 inches (193.97 mm)
Dimensions (without stand)
Height 12.35 inches (313.75 mm)
Width 20.33 inches (516.27 mm)
Depth 3.25 inches (82.46 mm)
Stand dimensions
Height 14.57 inches (370.2 mm)
Width 15.75 inches (400.1 mm)
Depth 7.64 inches (193.97 mm)
Weight
Weight with packaging 15.80 lbs (7.18 kg)
Weight with stand assembly and cables 13.05 lbs (5.92 kg)
Weight without stand assembly
(For wall mount or VESA mount
considerations - no cables) 8.75 lbs (3.97 kg)
Weight of stand assembly 4.30 lbs (1.95 kg)
