Dell AW2210 Monitor - Manual (Page 5)

Bottom view
Label Description
1 AC power cord connector
2 HDMI connectors (2)
3 DVI connector
4 Audio Line-in
5 Audio Line-out
6 USB upstream port
7 USB downstream ports (4)
Monitor Specifications
Flat Panel Specifications
* AW2210 color gamut (typical) is based on CIE1976 (85%) and CIE1931 (72%) test standards.
Model AW2210
Screen type Active matrix - TFT LCD
Panel type TN
Screen dimensions 21.5 inches (21.5-inch viewable image size)
Preset display area:
Horizontal 476.64 mm (18.77 inches)
Vertical 268.11 mm (10.56 inches)
Pixel pitch 0.248 mm
Viewing angle 160° (vertical) typ, 170° (horizontal) typ
Luminance output 300 cd/m ²(typ)
Contrast ratio 1000 to 1 (typ)
Dynamic contrast ratio Up to 80,000 : 1 (max)
Faceplate coating Antiglare with hard-coating 3H
Backlight 4 CCFL
Response Time 2ms typical (Grey to Grey)
Color gamut (Typical) 85%*
