Top Bracket
Dell™ Inspiron™ 410 Service Manual
Removing the Top Bracket
1.
Follow the procedures in
Before You Begin
.
2.
Remove the top cover (see
Removing the Top Cover
).
3.
Remove the two screws that secure the wireless antennas to the top bracket.
4.
Remove the two screws that secure the top bracket to the chassis.
5.
Lift the top bracket away from the computer.
WARNING:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION:
Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell™
is not covered by your warranty.
CAUTION:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on your computer).
1
screws (2)
2
wireless antennas (2)
1
screws (2)
2
top bracket
