Dell Latitude 2120 (Late 2010) User Manual
Page 2
Back View
WARNING:
Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow
environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer
turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer.
1 network activity indicator (optional)
2 line-out connector (headphone connector)
3 line-in connector (microphone connector)
4 USB 2.0 connector
5 cooling vents
6 video connector (VGA)
7 security cable slot
HW7HDam0.fm Page 2 Thursday, September 23, 2010 1:44 PM
