Setup and Features Information
Front View
1 microphone
2 camera status light (optional)
3 camera (optional)
4 right speaker
5 keyboard status lights (3)
6 power button
7 security cable slot
8 power connector
9 network connector
10 USB 2.0 connectors (2)
11 cooling vents
12 Secure Digital (SD) memory-card reader
13 touchpad buttons (2)
14 touchpad
15 cooling vents
16 device status lights (4)
17 keyboard
18 volume control buttons (3)
19 display (multi touch-screen feature is optional)
20 left speaker
Regulatory Model: P02T Regulatory Type: P02T002
Dell Latitude 2120 About Warnings
WARNING: A WARNING indicates a potential
for property damage, personal injury, or death.
September 2010
