Back to Contents Page
Back
NIC RJ-45 (for integrated 1-Gigabit NIC)
Serial 9-pin, DTE, 16550-compatible
USB Five 4-pin, version 2.0
Video 15-pin VGA
Front
USB Two 4-pin, version 2.0
Internally accessible
IDE channel 40-pin
SATA channels Four 7-pin
Video
Video type Integrated
Video memory 8 MB
Power
AC power supply (per power supply)
Wattage 305 W
Voltage 115–230 VAC, 60/50 Hz, 9.0-4.5 A
Heat dissipation 1040 BTU/hr maximum
Maximum inrush current Under typical line conditions and over the entire
system ambient operating range, the inrush current
may reach 140 A for 10 ms or less
Batteries
System battery CR 2032 3.0-V lithium ion coin cell
Physical
Height 44.5 cm (17.5 inches)
Width 16.76 cm (6.6 inches)
Depth 45.7 cm (18 inches)
Weight (maximum configuration) 17.24 kg (38 lb)
Environmental
Temperature
Operating 10° to 35°C (50° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity
Operating 8% to 85% (noncondensing) with a maximum
humidity gradation of 10% per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.25 G at 3–200 Hz for 15 min
Storage 0.5 G at 3–200 Hz for 15 min
Maximum shock
Operating One shock pulse in the positive z axis (one pulse on
each side of the system) of 41 G for up to 2 ms
Storage Six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse on
each side of the system) of 71 G for up to 2 ms
Altitude
Operating – 16 to 3048 m (–50 to 10,000 ft)
Storage – 16 to 10,600 m (–50 to 35,000 ft)
