Replacing the Base Cover | 15
Replacing the Base Cover
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
"Before Working Inside Your Computer" on page 11. After working
inside your computer, follow the instructions in "After Working Inside
Your Computer" on page 13.
For more safety best practices, see the Regulatory Compliance
home page at dell.com/regulatory_compliance.
Procedure
1 Align the tabs on the base cover with the slots on the computer base
2 Slide the base cover toward the back of the computer and align the screws holes on
the base cover with the screw holes on the computer base.
3 Replace the screws that secure the base cover to the computer base.
