Figure 1. Removing and Installing a RAID Controller Module
Installing a Replacement RAID Controller Module
1 Carefully insert the replacement RAID controller module into the empty
module slot.
2 Push the module into the back of the slot until it is firmly seated in the
backplane connector (see Figure 1).
3 Push the release lever in (towards the enclosure) until the module is retracted
into the slot and is secure.
Proceed to the next section to update the RAID controller and NVSRAM
firmware on the new controller.
1 release tab 2 release lever
2
1
