Power Button Board 35
8
Power Button Board
WARNING: Before working inside your computer, read the safety information
that shipped with your computer. For additional safety best practices information,
see the Regulatory Compliance Homepage at
www.dell.com/regulatory_compliance.
CAUTION: Only a certified service technician should perform repairs on your
computer. Damage due to servicing that is not authorized by Dell is not covered by
your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on your computer).
CAUTION: To help prevent damage to the system board, remove the main battery
(see "Removing the Battery" on page 13) before working inside the computer.
Removing the Power Button Board
1 Follow the instructions in "Before You Begin" on page 9.
2 Remove the battery (see "Removing the Battery" on page 13).
3 Follow the instructions from step 3 to step 8 in "Removing the Palm-Rest
Assembly" on page 29.
4 Turn the palm-rest assembly over.
5 Remove the screw that secures the power button board to the palm rest.
6 Push and release the tabs that secure the power button board to the palm
rest.
7 Lift the power button board along with its cable away from the palm rest.
