Dell ™ Latitude™ E6400 XFR Setup and Features Information
Page 12
1 Enclosed smart-card reader
The Smart Card can be fully inserted, allowing the protective hinged door to be closed. Insert
the card into the smart card slot with the gold contact pad facing upward and pointing toward
the smart card slot. Slide the card into the slot until it is fully seated in its connector.
To release the smart card, press in on the card edge and the reader will eject the card.
2. Contactless Smart Cards ( ) — these cards do not require any physical contact with the
reader. The chip communicates with the card reader through RFID induction technology. These
cards require only close proximity to an antenna of a card reader to complete transactions.
The Contactless Smart Card access is provided to the right of the keyboard touch pad.
DirectVue™ Touch Display Information
The computer provides an optional touch screen display for entering and selecting data using an
approved pointing device such as your finger, a passive stylus or any non-abrasive smooth blunt
object that will not damage the touch display.
NOTE: To ensure you properly care for and maintain your touch display, adhere to the care
instructions regarding the display.
WARNING: The optional DirectVue
TM Touch Display has been designed to accept finger
touch as well as passive stylus input directly onto the screen. With the optional
DirectVue TM Touch Display, a stylus is included with the computer for use in selecting
items on the touch screen. Other pointing devices can be used with the touch screen
such as any non-abrasive, smooth or blunt object that will not damage the touch
screen display. The touch screen surface can be damaged by ink pens, marker pens or
other pointed or abrasive objects. The use of non-approved input devices that cause
damage to the digitizer or LCD may not be covered by the limited warranty.
The touch screen is pre-configured and pre-calibrated at the factory, but may require further
calibration to improve accuracy for entering or selecting data on the touch display. Please see the
Tools section for information on Calibrating your Touch Display and using your stylus.
Accessing Drivers and Documentation
Your DirectVue Touch Display’s drivers, touch-input parameters and documentation have been pre-
loaded at the factory. For experienced users or IT administrators - if you need to re-install drivers, set
up your Touch Display or modify parameters please refer to the pre-loaded Touchkit Utility
documentation for detailed instructions and refer to the summary provided in Touchkit
Configuration Utility.
1
