Dell S2340T Multi Touch Monitor User Manual

Page 24

Push the

and

buttons to move between the setting options. As you move from one icon to another, the option name is highlighted. See the following

table for a complete list of all the options available for the monitor.

Push the

button once to activate the highlighted option.

Push

and

button to select the desired parameter.

5. Push

to enter the slide bar and then use the

and

buttons, according to the indicators on the menu, to make your changes.

Select the

button to return to the main menu.

Icon

Menu and

Submenus

Description

Brightness/Contrast Use this menu to activate Brightness/Contrast adjustment.

Brightness

Brightness adjusts the luminance of the backlight.

Push the

button to increase brightness and push the

button to decrease brightness (min 0 ~ max 100).

1, Green Mode is turned ON by default.
2, In Green Mode, the maximum brightness is optimally adjusted to meet Energy Star requirements. Power saving is done for the user

automatically.
3, If the user prefers a brighter setting, exit Green Mode by following these steps:
