Preset Display Modes
Display Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (Horizontal/Vertical)
VGA, 720 x 400 31.5 70.0 28.3 -/+
VGA, 640 x 480 31.5 60.0 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.0 40.0 +/+
VESA, 800 x 600 46.9 75.0 49.5 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
MAC, 1152 x 864 67.5 75.0 108.0 +/+
SXGA, 1280 x 1024 64.0 60.0 108.0 +/+
SXGA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA STD, 1600 x 900 60.0 60.0 108.0 +/+
FHD, 1920 x 1080 67.5 60.0 148.5 +/+
Electrical Specifications
Video input signals DP 1.2/HDMI 1.4/USB signal input support
AC/DC adaptor input
voltage/frequency/current
100 VAC to 240 VAC / 50 Hz or 60 Hz + 3 Hz / 1.5 A (Typical)
Inrush current 115 V / 230 V: 150 A (Max)
monitor input voltage 19.5Vdc, 4.62A
Physical Characteristics
Connector type HDMI/DisplayPort/USB, black connector
Signal cable type DisplayPort: Detachable, DisplayPort, Solid pins
High Definition Multimedia Interface: Detachable, HDMI, 19 pins
Universal Serial Bus: Detachable, USB, 9 pins
Extended to highest position
Height (extended) 415.0 mm (16.3 inches)
Width 562.2 mm (22.1 inches)
Depth 218.0 mm (8.6 inches)
Compressed to lowest position
Height 88.0 mm (3.5 inches)
