Using the On-Screen Display (OSD) Menu
Accessing the Menu System
Main Menu for Analog (VGA) Input
or
Main Menu for non Analog (non VGA) Input
or
or
B
Picture by Picture
(PBP) Select
Use this button to activate Picture by Picture (PBP) mode adjustment.
C
OSD Menu/Select
Use the MENU button to launch the on-screen display (OSD) and select the OSD Menu. See Accessing the Menu System .
D
Brightness/Contrast
Hot Key
Use this button for direct access to the "Brightness" and "Contrast" control menu.
E
Down (-) and Up (+)
Use these buttons to navigate and adjust the slider-bar (decrease/increase ranges) controls in the OSD.
F
Auto Adjust
Use this button to activate automatic setup and adjust menu. The following dialog appears on a black screen as the monitor self-adjusts
to the current input:
Auto Adjustment allows the monitor to self-adjust to the incoming video signal. After using Auto Adjustment, you can further tune your
monitor by using the Pixel Clock (Coarse) and Phase (Fine) controls under DISPLAY SETTINGS.
NOTE: Auto Adjust does not occur if you press the button while there are no active video input signals or attached cables.
G
Power button
(with power light
indicator)
Use the Power button to turn the monitor on and off.
The blue LED indicates the monitor is on and fully functional. An amber LED indicates DPMS power save mode.
NOTE: If you change the settings and then either proceed to another menu or exit the OSD menu, the monitor automatically saves those
changes. The changes are also saved if you change the settings and then wait for the OSD menu to disappear.
1. Push the MENU button to launch the OSD menu and display the main menu.
