Dell Inspiron E1705 User Manual
Page 134
134
Adding and Replacing Parts
If you ordered a card with Bluetooth wireless technology with your computer, it is already installed.
1 Follow the procedures in "Before You Begin" on page 117.
2 Remove the battery. See "Replacing the Battery" on page 47.
3 Loosen the captive screw and remove the card cover from the computer.
4 Pull the card out of the compartment so that you can disconnect the card from its cable and remove it
from the computer.
5 To replace the card, connect the card to the cable and then carefully insert it into the compartment.
6 Replace the card cover and tighten the screw.
7 Replace the battery.
1
cable connector
2
card
3
card cover
3
2
1
PD598a01.book Page 134 Monday, February 6, 2006 2:24 PM
