Wall mounting (optional) – Dell E2014T 19.5 Multi-Touch Monitor with LED User Manual

Page 21

Setting Up the Monitor



To remove the stand:

1. Place the monitor on a flat surface.
2. Press and hold the Stand release button.
3. Lift the stand up and away from the monitor.

Wall Mounting (Optional)

NOTE:

Use M4 x 10 mm screws to mount your display. For more details, see

the instructions that came with the VESA-compatible wall-mounting kit.

1. Place the monitor on a soft cloth or cushion on a stable flat table.

2. Remove the stand.

3. Use a screwdriver to remove the four screws that secure the back cover.

4. Attach the mounting bracket from the wall-mounting kit to the monitor.

5. Mount the monitor on the wall by following the instructions that came with the

wall mounting kit.

NOTE:

For use only with UL-listed wall-mount bracket with

minimum weight/load bearing capacity of 3.43 kg.
