Display Panel
Removing the Display Panel
1. Follow the instructions in Before You Begin .
2. Remove the display assembly (see Removing the Display Assembly ).
3. Remove the display bezel (see Removing the Display Bezel ).
4. Remove the four screws securing the display panel to the cover.
5. Disconnect the cables from the connectors on each end of the inverter.
6. Lift the display panel out of the display cover.
7. Remove the four screws (two on each side of the display panel) securing the brackets to the display panel and remove the brackets.
CAUTION: Before you begin the following procedure, follow the safety instructions that shipped with your computer.
CAUTION: The following instructions are not applicable to Edge-to-Edge display panels, which should not be disassembled.
1 screws (4) 2 display panel
1 inverter 2 connectors (2)
