10  About Your Monitor About Your Monitor  11
Back View Side View
Back view Back view with monitor stand
Label Description Use
1 VESA mounting holes (100
mm x 100 mm - behind
attached VESA Cover)
Wall mount monitor using VESA-
compatible wall mount kit (100 mm x
100 mm).
2 Regulatory label Lists the regulatory approvals.
3 Security lock slot Use a security lock to secure the
monitor. (security lock not included).
4 Barcode serial number
label
Refer to this label if you need to contact
Dell for technical support.
5 Stand release button Release stand from monitor.
6 Dell Soundbar mounting
slots
Attaches the optional Dell Soundbar.
7 Cable management slot Use to organize cables by placing them
through the slot.
Bottom View
Bottom view
Label Description Use
1. AC power connector To connect the monitor power cable.
2. DP connector Connect your computer DP cable.
3 DVI connector To connect your computer to the monitor
using a DVI cable.
4 VGA connector To connect your computer to the monitor
using a VGA cable.
5 USB upstream port Connect the USB cable that came with your
monitor to the monitor and the computer.
Once this cable is connected, you can use the
USB connectors on the monitor.
