Dell P2014H Monitor - Manual (Page 22)

42  Operating the Monitor Operating the Monitor  43
OSD Warning Messages
When the monitor does not support a particular resolution mode you will
see the following message:
This means that the monitor cannot synchronize with the signal that it is
receiving from the computer. See
Monitor Specifications for the Horizontal
and Vertical frequency ranges addressable by this monitor. Recommended
mode is 1600 x 900.
You will see the following message before the DDC/CI function is disabled.
When monitor enters Power Save mode, the following message appears:
Activate the computer and wake up the monitor to gain access to the OSD
If you press any button other than the power button one of the following
messages will appear depending on the selected input:
If either VGA or DVI-D or DP input is selected and both VGA and DVI-D and
DP cables are not connected, a floating dialog box as shown below appears.
or
or
See Solving Problems for more information.
Setting the Maximum Resolution
In Windows Vista ® , Windows ® 7 or Windows ® 8:
1. For Windows ® 8 only, select the Desktop tile to switch to classic desktop.
2. Right-click on the desktop and click Screen resolution.
3. Click the Dropdown list of the Screen resolution and select 1600 x 900.
4. Click OK.
If you do not see 1600 x 900 as an option, you may need to update your
