Be sure that you securely anchor the keyboard to the stand
using the L butterfly bolts (Figure 6).
• Slide the screws on the bottom of the keyboard into the
slots in the two angle brackets G. Next, secure the keyboard
to the stand with two butterfly bolts L (Figure 7).
Figure 7
6. Rotate height adjustment screw H until it supports
crosspiece D, preventing the crosspiece from bending when
you press the pedals (Figure 5).
IMPORTANT!
• Be sure to install adjustment screw H and perform the ad-
justment procedure described above before depressing
the pedals. Failure to do so can result in damage to cross-
piece D.
5. Attach back panel C to the F brackets and crosspiece D.
Note that the back panel C should be installed so it is in
front of the F brackets (Figure 4). Use the four M screws,
six J screws to secure the back panel in place (Figures 3
and 4). Note that you must also install the second K clip at
this time as shown in the illustration.
• First, install the topmost M screws on the left and right
sides of the back panel C. Note that you should slip the
other K clip onto the J screw at point 6 before you
screw in the J screw.
• The back panel C should rest on the feet of side uprights
A and B as indicated by 7 in the illustration. Press the
back panel C against crosspiece D while installing the
M screws.
Figure 4
Figure 5
H
(Back) A
C B
J
M
M
7
6
K
K
F
2 Installing the Keyboard
onto the Stand
Caution
Take care that you do not pinch your fingers between
the keyboard and stand!
• The butterfly bolts keep the keyboard from falling from the
stand. Be sure that you always secure the keyboard with
the butterfly bolts.
L G
Front
Back
