About Your System Board
Dell Precision™ T7500 Service Manual
System Board Schematic
1 SATA Connectors (SATA0-3)
18 Front Panel Audio Connector
(FP_AUDIO)
2 Main Power Connector (POWER1)
19 Type A USB Port (INT_USB2)
3 SAS Connectors (HDD0-3)
20 Rear Fan Connector (FAN_REAR)
4 Hard Drive Fan Connector
(FAN_HDD)
21 CPU Riser 2 (CPU2_RSR2)
