Adit 3104 - Release 1.6
23
Quick Start
Basic Configuration
Basic Configuration
The following configuration is divided into logical sections, where each section configures an additional
function. The first must be configured before the second and so forth, however, you may stop at any
section and not add the following feature.
NOTE:
The order in which commands are entered can affect the successful provisioning of
the Adit 3104.
z
Setup Adit for access via Web-Browser
z
z
z
Configure Ethernet WAN Interface
z
z
Configure the Adit 3104 as a SIP Line Gateway
Setup Adit for access via Web-Browser
The following steps will configure the Adit 3104 to allow access to the Web Browser for configuration,
through one of the 4 10/100Base-T LAN connections.
Note: for LAN access, no additional configuration is required to access the Adit using the web browser.
To configure the WAN access:
1. Connect to the CLI via the DB-9 RS-232. See Setting up a CLI Connection on page 20.
2. Enable the remote admin WAN access with the following command sequence:
Command
Description
Username: admin
Password: ********
Log into the system (username and password).
Adit 3104> enable
Enter the Privileged mode.
Password: ********
Enter password for the Privileged mode.
#configure terminal
Enter the Configuration mode.
(config)# remote-admin web
primary-port enable
Enable remote web admin.
