Dell PowerEdge 850 - Manual (Page 3)

PS/2-style keyboard 6-pin mini-DIN
PS/2-compatible mouse 6-pin mini-DIN
Serial 9 pin
USB Two 4-pin, USB 2.0 compliant
Video 15-pin VGA
Front
Video 15-pin VGA
USB Two 4-pin, USB 2.0 compliant
Internally accessible
IDE channel 40 pin
SATA channels Two 7 pin
Video
Video type Integrated XGI XG20 VGA controller
Video memory 16 MB
Power
AC power supply
Wattage 345 W
Voltage 100–240 VAC, 50/60 Hz
Maximum inrush current Under typical line conditions and over the entire
system ambient operating range, the inrush current
may reach 25 A for 10 ms or less.
System battery CR 2032 3.0-V lithium ion coin cell
Physical
Height 4.2 cm (1.68 in)
Width 44.6 cm (17.6 in)
Depth
With optional bezel 57.6 cm (22.7 in)
Without optional bezel 54.6 cm (21.5 in)
Weight (maximum configuration) 11.8 kg (26 lb)
Environmental
NOTE: For additional information about environmental measurements for specific system configurations,
see www.dell.com/environmental_datasheets.
Temperature
Operating 10° to 35°C (50° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity
Operating 8% to 85% (noncondensing) with a maximum
humidity gradation of 10% per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.25 G at 3–200 Hz for 15 min
Storage 0.5 G at 3–200 Hz for 15 min
Maximum shock
Operating One shock pulse in the positive z axis (one pulse on
each side of the system) of 41 G for up to 2 ms
Storage Six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse on
each side of the system) of 71 G for up to 2 ms
Altitude
Operating – 16 to 3048 m (–50 to 10,000 ft)
Storage – 16 to 10,600 m (–50 to 35,000 ft)
