CPU Information Screen
lists the options and descriptions for the information fields that appear on the CPU Information screen.
Table 2-3. CPU Information Screen
Integrated Devices Screen
lists the options and descriptions for the information fields that appear on the Integrated Devices screen.
Table 2-4. Integrated Devices Screen Options
Console Redirection Screen
lists the options and descriptions for the information fields that appear on the Console Redirection screen.
Table 2-5. Console Redirection Screen Options
Report Keyboard
Errors
(Report default)
Enables or disables reporting of keyboard errors during the POST. Enable this option for host systems that have keyboards attached.
Select Do Not Report to suppress all error messages relating to the keyboard or keyboard controller during POST. This setting does not
affect the operation of the keyboard itself if a keyboard is attached to the system.
Asset Tag
Displays the customer-programmable asset tag number for the system if an asset tag number has been assigned.
Option
Description
Bus Speed
Displays the bus speed of the processors.
Logical Processor
(Enabled default)
Displays when the processors support Hyper-Threading technology. Enabled permits all logical processors to be used by the
operating system. Only the first logical processor of each processor installed in the system is used by the operating system if
Disabled is selected.
Demand-Based Power
Management
(Disabled default)
When set to Enabled, the CPU Performance State Tables are reported to the operating system. When set to Disabled, the
Performance State Tables are not reported to the operating system.
If the processor does not support Demand-Based Power Management, this field is read-only.
Processor 1 ID
Displays the family and model number of each processor.
Core Speed
Displays the clock speed of the processor(s).
Level 2 Cache
Displays the amount of cache memory for the processor.
64-Bit Technology
Specifies if the installed processor supports Intel® 64-bit extensions.
Option
Description
IDE Controller
(Auto default)
Enables the integrated IDE controller. When set to Auto, each channel of the integrated IDE controller is enabled if IDE devices are
attached to the channel and the external IDE controller is not detected.
SATA Controller
(ATA default)
Allows the integrated SATA controller to be set to Off or ATA Mode. Off disables the SATA subsystem. ATA Mode sets the SATA
subsystem to Native IDE mode.
USB Controller
(On with BIOS
support default)
Enables or disables the system's USB ports. Options are On with BIOS support, On without BIOS support, or Off. Disabling the USB
ports makes system resources available for other devices.
Embedded Gb NIC
(Enabled with PXE
default)
Enables or disables the system's integrated NIC. Options are Enabled with PXE and Disabled. PXE support allows the system to boot
from the network. Changes take effect after the system reboots.
MAC Address
Displays the MAC address for the integrated 10/100/1000 NIC. This field does not have user-selectable settings.
Secondary
Embedded Gb NIC
Enables or disables the system's secondary integrated NIC. Options are Enabled without PXE and Disabled. PXE support allows the
system to boot from the network. Changes take effect after the system reboots.
Secondary NIC MAC
Address
Displays the MAC address for the secondary integrated 10/100/1000 NIC. This field does not have user-selectable settings.
Serial Port
(COM1 default)
Serial Port 1 options are COM1, COM3, BMC Serial, BMC NIC, and Off. If an optional remote access controller (RAC) is installed in the
system, RAC is an additional option.
Serial port 1 shares three usage models. For standard usage, serial port 1 attempts to use COM1 first, and then COM3. For BMC usage,
serial port 1 uses the COM1 address and communication can be either via the Serial port or the integrated shared NIC. RAC control
uses only the COM1 address.
NOTE:
Off and COM3 are not available options when Console Redirection is set to use Serial Port 1.
Speaker
(On default)
Enables or disables the system internal speaker.
