Installing The System Fan
1. Place the system fan in the chassis.
2. Pass the four grommets through the chassis and slide outwards along the grooves to secure them in place.
3. Thread the system-fan cable into the chassis clips.
4. Connect the system-fan cable to the system board.
5. Install the front bezel .
6. Install the cover .
7. Follow the procedures in After Working Inside Your Computer .
Related Links
Removing The System Fan
Removing The Input/Output Panel
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the cover .
3. Remove the front bezel .
4. Disconnect the Input/Output panel or the FlyWire cable from the system board.
5. Remove the screw that secures the Input/Output panel to the chassis.
6. Slide the Input/Output panel towards the right of the system to release from chassis.
