Dell ™ Latitude™ XT2 XFR Setup and Features Information
Page 8
NOTE: It is recommended that you turn on and shut down your computer at least once before
you install any cards or connect the computer to a docking device or other external device, such
as a printer.
Battery
Battery Removal
1. Ensure that the computer is turned off.
2. If the computer is connected to a docking device (docked), undock it. See the documentation
that came with your docking device for instructions.
3. Ensure that the computer is turned off.
4. Turn the computer upside down and place on a flat surface.
5. Lift the locking latches on the left and right side of the battery.
6. Push the locking latches outward, as shown below.
