Dell ™ Latitude™ XT2 XFR Setup and Features Information
Page 3
Back and Left View
1 Speaker 9 Tablet grip
2 IEEE 1394 connector 10 Rotating hinge
3 USB connector (for power share) 11 Powered USB connector
4 QuadCool™ Thermal Management 12 Network connector
5 Pen tether anchor 13 Video connector
6 Pen 14 AC adapter connector
7 Pen indicator LED 15 Tablet back button
8 Power / battery charge indicators 16 Scroll control button
WARNING : Do not block, push objects into, or allow dust to accumulate in the air
vents. Do not store your Dell™ computer in a low-airflow environment, such as a
closed briefcase, while it is running. Restricting the airflow can damage the computer
or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise
is normal and does not indicate a problem with the fan or the computer.
1
4
3
2
8
7
6
5
12
11
10
9
13
14
15
16
