Replacing the Card Reader Board
1. Align the card reader board using the alignment posts on the computer base.
2. Replace the screw that secures the card reader board to the computer base.
3. Connect the card reader cable to the connector on the system board.
4. Replace the left speaker (see Replacing the Speakers ).
5. Replace the hard drive (see Replacing the Hard Drive ).
6. Replace the palm rest (see Replacing the Palm Rest ).
7. Replace the keyboard (see Replacing the Keyboard ).
8. Replace the power button cover (see Replacing the Power Button Cover ).
9. Replace the Mini-Card (see Replacing the Mini-Card ).
10. Replace the module cover (see Replacing the Module Cover ).
11. Replace the optical drive (see Replacing the Optical Drive ).
12. Replace the battery (see Replacing the Battery ).
Back to Contents Page
1 screw 2 card reader cable
3 card reader board 4 alignment posts (2)
