Replacing the Camera Module | 91
38 Replacing the Camera Module
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 7. After working inside your computer, follow the instructions in "After
Working Inside Your Computer" on page 9. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
Procedure
1 Align the camera module on the display back-cover.
2 Connect the camera cable to the connector on the camera module.
Postrequisites
1 Replace the display bezel. See "Replacing the Display Bezel" on page 77.
2 Replace the display assembly.
See "Replacing the Display Assembly" on page 73.
3 Replace the system board. See "Replacing the System Board" on page 61.
4 Replace the wireless Mini-Card.
See "Replacing the Wireless Mini-Card" on page 41.
5 Replace the hard drive. See "Replacing the Hard Drive" on page 37.
6 Replace the battery. See "Replacing the Battery" on page 33.
7 Replace the palm-rest assembly.
See "Replacing the Palm-Rest Assembly" on page 29.
8 Replace the keyboard. See "Replacing the Keyboard" on page 23.
9 Replace the optical drive.
See "Replacing the Optical-Drive Assembly" on page 17.
10 Replace the memory module(s).
See "Replacing the Memory Module(s)" on page 13.
11 Follow the instructions in "After Working Inside Your Computer" on page 9.
