Dell Inspiron 15 (1564, Early 2010) - Manual (Page 20)

9. Pull the Mini-Card antenna cables up through the slot in the computer base.
10. Note the routing of the Mini-Card antenna cables and remove them from the routing guides on the palm rest.
11. Disconnect the display cable from the connector on the system board, and remove the display cable grounding screw.
12. Hold the display assembly in place and remove the three screws that secure the display assembly to the computer base.
13. Lift the display assembly off the alignment posts on the computer base.
Replacing the Display Assembly
1. Follow the procedures in Before You Begin .
2. Use the alignment posts to place the display assembly on the computer base.
3. Replace the three screws that secure the display assembly to the computer base.
1 Mini-Card antenna cable routing 2 display cable grounding screw
3 display cable 4 slot in computer base
1 display assembly 2 screws (3)
3 display hinges (2)
