28
Cabling Your Cluster Hardware
Configuring Your Cluster With SAN Backup
You can provide centralized backup for your clusters by sharing your SAN
with multiple clusters, storage systems, and a tape library.
Figure 2-11 provides an example of cabling the cluster nodes to your storage
systems and SAN backup with a tape library.
Figure 2-11. Cluster Configuration Using SAN-Based Backup
cluster 2 cluster 1
Fibre Channel switch
storage systems
tape library
Fibre Channel switch
