Dell AX4-5 User Manual
Page 22
22
Cabling Your Cluster Hardware
Figure 2-7.
Eight-Node SAN-Attached Cluster
Each HBA port is cabled to a port on a Fibre Channel switch. One or more
cables connect from the outgoing ports on a switch to a storage processor on a
Dell|EMC storage system.
public network
storage system
cluster
nodes (8)
Fibre
Channel
switch
Fibre
Channel
switch
private
network
