6 Dell Inspiron 3700 System Advanced Port Replicator User’s Guide
%
&'
"%"
%
%
-
"
"
2. To prepare the computer for undocking, perform one of the following procedures:
Press on the computer's keyboard (or press Lock> on an external keyboard).
Wait a few seconds for the power indicator on the computer to turn off.
If you are using the Microsoft ® Windows ® 98 operating system, click the
Start button, and then click Eject PC. If you are using the Microsoft Win-
dows NT
®
operating system, click the docking icon and then click Undock to
place the computer in standby mode.
Wait a few seconds for the power indicator on the computer to turn off.
Press the undock request button on the APR (see Figure 5). Wait for the
green docking indicator to turn off.
3. Pull the eject/locking lever on the left side of the APR (see Figure 5) to undock the
computer.
) *!
'(
eject/locking lever
