Dell Rugged Desk Dock - Manual (Page 19)

Specifications
Physical
Height 67.2 mm (2.64 inches)
Depth 277.5 mm (10.93 inches)
Width 304.8 mm (12.00 inches)
System Level Operational Specifications
Serial (DTE) two 9-pin connectors, 16550-compatible,
16-byte buffer
USB four USB connectors:
one USB 2.0-compliant connector, three USB
3.0-compliant connectors
Audio headset/speakers and one microphone
Network one RJ-45 port; 10/100/1000 Mbps Ethernet
Dell Rugged docking connector one custom connector (Dell Rugged Family
only)
Video one HDMI connector and one VGA
connector
AC Adapter Power
Input Voltage Wattage Amperage
100-240 VAC, 50-60 Hz 130W* 1.8A
Feature Specification
Temperature range:
Operating
Storage
0 °C to 40 °C (32 °F to 104 °F)
-40 °C to 65 °C (-40 °F to 149 °F)
Relative humidity (maximum):
Operating
Storage
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude:
Storage 0 m to 10668 m (0 ft to 35,000 ft)
