Dell Precision M2800 (Early 2014) - Manual (Page 22)

Installing the Network Connector
1. Align the network connector to its position on the computer.
2. Place the network-connector bracket on the network connector.
3. Tighten the screw to secure the network-connector bracket to the computer.
4. Route the cable through the routing channel.
5. Connect the cable to the system board.
6. Install:
a. base-corner cover (left)
b. base cover
c. battery
7. Follow the procedures in After Working Inside Your Computer .
Removing the Coin-Cell Battery
1. Follow the procedures in Before Working Inside your computer .
2. Remove:
a. battery
b. base cover
3. Disconnect the coin-cell battery cable, pry the coin-cell battery upward, and remove the coin-cell
from the computer.
22
