26 Keyboard
CAUTION: Exercise caution while lifting up the keyboard to avoid pulling the
keyboard connector from the system board forcefully.
6 Carefully lift the keyboard and slide the keyboard tabs out of the slots on
the palm-rest assembly.
7 Turn the keyboard over and place it on the palm-rest assembly.
8 Lift the connector latch and disconnect the keyboard cable from the
connector on the system board.
9 Lift the keyboard off the palm-rest assembly.
1 plastic scribe 2 keyboard
3 palm-rest assembly
1
2
3
