80 Snapshot Virtual Disks
15 Click Finish to create the snapshot virtual disk and the associated
snapshot repository virtual disk.
16 After you have created one or more snapshot virtual disks, mount or
reassign a drive letter of the source virtual disk.
17 If needed, assign host-to-virtual disk mapping between the snapshot
virtual disk and the host operating system that accesses it.
NOTE: In some cases, depending on the host type and any virtual disk
manager software in use, the software prevents you from mapping the same
host to both a source virtual disk and its associated snapshot virtual disk.
18 If you are using a Linux-based system, run the hot_add utility to register
the snapshot virtual disk with the host operating system.
NOTE: The hot_add utility is not needed for Windows.
Specifying Snapshot Virtual Disk Names
Choose a name that helps you associate the snapshot virtual disk and
snapshot repository virtual disk with its corresponding source virtual disk. The
following information is useful when naming virtual disks:
• By default, the snapshot name is shown in the Snapshot virtual disk name
field as:
<source-virtual disk-name>—<sequence-number>
where sequence-number is the chronological number of the snapshot
relative to the source virtual disk.
The default name for the associated snapshot repository virtual disk that is
shown in the Snapshot repository virtual disk field is:
<source-virtual disk-name>—R<sequence-number>
For example, if you are creating the first snapshot virtual disk for a source
virtual disk called Accounting, the default snapshot virtual disk is
Accounting-1, and the associated snapshot repository virtual disk default
name is Accounting-R1. The default name of the next snapshot virtual
disk you create based on Accounting is Accounting-2, with the
corresponding snapshot repository virtual disk named as Accounting-R2 by
default.
