124 Right-Side Bottom Panel
Postrequisites
1 Replace the right-side middle panel. See "Replacing the Right-Side Middle
Panel" on page 114.
2 Replace the right lighting-board. See "Replacing the Right Lighting-Board"
on page 118.
3 Replace the right-side top panel. See "Replacing the Right-Side Top Panel"
on page 110.
4 Replace the power-supply unit. See "Replacing the Power-Supply Unit" on
page 86.
5 Replace the hard-drive fan assembly. See "Replacing the Hard-Drive Fan
Assembly" on page 34.
6 Replace the drive-bay shroud. See "Replacing the Drive-Bay Shroud" on
page 48.
7 Close the PCI shroud. See "Closing the PCI Shroud" on page 46.
8 Replace the left side-panel. See "Replacing the Left Side-Panel" on
page 27.
9 Follow the steps in "After Working Inside Your Computer" on page 15.
