Right-Side Middle Panel 113
23
Right-Side Middle Panel
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 13. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1 Remove the left side-panel. See "Removing the Left Side-Panel" on
page 25.
2 Open the PCI shroud. See "Opening the PCI Shroud" on page 45.
3 Remove the drive-bay shroud. See "Follow the steps in "After Working
Inside Your Computer" on page 15." on page 46.
4 Remove the right-side top panel. See "Removing the Right-Side Middle
Panel" on page 113.
5 Remove the right lighting-board. See "Removing the Right Lighting-
Board" on page 117.
Removing the Right-Side Middle Panel
1 Remove the screws that secure the right-side middle panel to the chassis.
2 Lift the right-side middle panel up and away from the chassis.
