8
Solid-State Drive
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 9. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
CAUTION: To avoid data loss, do not remove the solid-state drive while the
computer is On or in Sleep state.
CAUTION: Solid-state drives are extremely fragile. Exercise care when handling
the solid-state drive.
Prerequisites
1 Remove the base cover. See "Removing the Base Cover" on page 13.
2 Remove the power-light board. See "Removing the Power-Light Board" on
page 15.
3 Remove the battery. See "Removing the Battery" on page 17.
Removing the Solid-State Drive
1 Peel the tape that is adhered over the solid-state drive.
1
1 tape
Remove the screw that secures the solid-state drive to the system board.
Solid-State Drive 27
2
