Dell E2209WFP Monitor - Manual (Page 6)

Video Supported Modes
Model E2009W/E2209W
Video display capabilities (DVI playback) 480i/480p/576i/576p/720p/1080i/1080p (Support HDCP)
Preset Display Modes
Display Mode
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal/Vertical)
VESA, 720 x 400 31.5 70.0 28.3 -/+
VESA, 640 x 480 31.5 60.0 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.0 40.0 +/+
VESA, 800 x 600 46.9 75.0 49.5 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
VESA, 1152 x 864 67.5 75.0 108.0 +/+
VESA, 1280 x 1024 64.0 60.0 135.0 +/+
VESA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA, 1680 x 1050 65.2 60.0 146.3 -/+
VESA, 1680 x 1050 64.6 60.0 119.0 +/-
Electrical Specifications
Model E2009W/E2209W
Video input signals
Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance
Digital DVI-D TMDS, 600mV for each differential line, positive polarity at 50 ohm input
impedance
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG
(Composite SYNC on green)
AC input voltage/frequency/current 100 to 240 VAC/50 or 60 Hz + 3 Hz/2.0A (Max.)
Inrush current
120V:40A (Max.)
240V:80A (Max.)
Physical Characteristics
Model E2009W E2209W
Connector type
15-pin D-subminiature, blue connector; DVI-D, white
connector
15-pin D-subminiature, blue connector; DVI-D, white
connector
Signal cable type
Digital: Detachable, DVI-D, Solid pins, shipped
detached from the monitor
Analog: Detachable, D-Sub, 15pins, shipped attached
to the monitor
Digital: Detachable, DVI-D, Solid pins, shipped detached
from the monitor
Analog: Detachable, D-Sub, 15pins, shipped attached to
the monitor
Dimensions (with stand)
Height 14.96 inches (380.0 mm) 16.01 inches (406.7 mm)
Width 18.5 inches (470.0 mm) 20.13 inches (511.2 mm)
Depth 6.24 inches (158.5 mm) 6.44 inches (163.9 mm)
Dimensions (without stand)
Height 12.1 inches (310.0 mm) 13.15 inches (334.0 mm)
Width 18.5 inches (470.0 mm) 20.13 inches (511.2 mm)
Depth 2.76 inches (70.0 mm) 2.54 inches (64.5 mm)
Stand dimensions
Height 11.34 inches (288.0 mm) 12.39 inches (314.7 mm)
Width 10.26 inches (260.5 mm) 10.47 inches (265.9 mm)
