Information Update
11
System Status Indicator Codes
The system bezel incorporates a system status indicator. The system status indicator lights blue
when the system is operating correctly and lights amber when the system needs attention due to a
problem with power supplies, fans, system temperature, or hard drives.
Table 1-1 lists the system's indicator patterns. Different patterns are displayed as events occur in
the system.
Hard-Drive Indicator Codes
Each SCSI hard-drive carrier has two indicators: a busy indicator on the bottom and a status
indicator on the top. The indicators provide information on the status of the respective hard drive.
Table 1-2 lists the drive status indicator codes. Different codes display as drive events occur in the
system. For example, in the event of a hard-drive failure, the "drive failed" code appears. After the
drive is selected for removal, the "drive being prepared for removal" code appears. After the
replacement drive is installed, the "drive being prepared for operation, drive online" code appears.
Table 1-1. System Status Indicator Patterns
Blue Indicator Amber Indicator Description
Off Off Power is not available to the
system.
Off Blinking The system has detected an
error and requires attention.
On Off Power is on, and the system is
operational.
Blinking Off The indicator has been activated
to identify the system in a rack.
NOTE:
While the system is being identified, the blue indicator blinks even though an error has been
detected. After the system is identified, the blue indicator stops blinking and the amber indicator
resumes blinking.
Table 1-2. SCSI Hard-Drive Status Indicator Codes
Indicator Indicator Code
Off Drive bay empty, ready for insertion or removal
Steady green Drive being prepared for operation, drive online
Blinks green four times per second Identify drive
Blinks green twice per second at equal intervals Drive being prepared for removal
Blinks green twice per second at unequal intervals Drive rebuilding
