Wall mounting (optional) – Dell P1914S Monitor User Manual

Page 31

Wall Mounting (Optional)

(Screw dimension: M4 x 10 mm).
Refer to the instructions that come with the VESA-compatible base
mounting kit.

1. Place the monitor panel on a soft cloth or cushion on a stable, flat

table.

2. Remove the stand.
3. Use a screwdriver to remove the four screws securing the plastic

cover.

4. Attach the mounting bracket from the wall mounting kit to the LCD.

5. Mount the LCD on the wall by following the instructions that came

with the base mounting kit.

NOTE:

For use only with UL-listed wall-mount bracket with minimum

weight/load bearing capacity of 6.86 kg

Setting Up the Monitor


