58
Specifi cations
Video
Discrete PCI Express x16 card
Audio
Type Integrated 7.1
channel, High
Definition Audio with
S/PDIF support
Communication
Wireless (optional) WiFi/Bluetooth
wireless technology
Physical
Height 493 mm (19.40 inches)
Width 198 mm (7.79 inches)
Depth 528 mm (20.78 inches)
Weight 20.01 kg (44.11 lb)
External connectors
Network adapter RJ45 connector
USB three top-panel, one
front-panel, and four
back-panel USB
2.0-compliant connectors
Audio top panel - one
microphone and one
headphone connector
back panel - six
connectors for 7.1 support
S/PDIF one S/PDIF (optical)
connector
eSATA one back-panel connector
IEEE 1394 one back-panel 6-pin
serial connector
